Range
| SIZE | In (A) | POLES | FIXING | CONNECTION | REFERENCE | |
|---|---|---|---|---|---|---|
| NH00 1P |
 |
160A | 1P | SCREW | SCREW | 354100 |
| CLAMP | 354105 | |||||
| CLAMP/SCREW | 354110 | |||||
| FIXED NUT | 354115 | |||||
| DIN RAIL + SCREW | SCREW | 352100 | ||||
| CLAMP | 352105 | |||||
| CLAMP/SCREW | 352110 | |||||
| FIXED NUT | 354115 | |||||
| NH00 3P |
 |
160A | 3P | DIN RAIL + SCREW | SCREW | 353102 |
| CLAMP | 353105 | |||||
| CLAMP/SCREW | 353110 | |||||
| FIXED NUT | 353115 | |||||
| NH00 3P WITH COVER SHIELDS |
 |
160A | 3P | DIN RAIL + SCREW WITH COVER SHIELDS |
SCREW | 335120 |
| CLAMP | 335125 | |||||
| CLAMP/SCREW | 335130 | |||||
| FIXED NUT | 335135 | |||||
| NH00 3P WITH IP20 PROTECTION |
 |
160A | 3P | DIN RAIL + SCREW WITH IP20 PROTECTION |
SCREW | 334717 |
| CLAMP | 334720 | |||||
| CLAMP/SCREW | 334725 | |||||
| FIXED NUT | 334730 | |||||
Technical data
| Contacts | Silver plated copper |
| Body | Thermoplastic, high resistance to temperature Flammability: (UL94) V0 Glow wire test: (IEC-60695) 960ºC Tracking resistance (IEC-112) CTI > 600V |
| Separating plates | Thermoplastic, high resistance to temperature Flammability: (UL94) V0 Glow wire test: (IEC-60695) 960ºC |
| Separators | Thermoplastic, high resistance to temperature Flammability: (UL94) V0 Glow wire test: (IEC-60695) 960ºC |
| Terminal covers | Thermoplastic, high resistance to temperature Flammability: (UL94) V0 Glow wire test: (IEC-60695) 960ºC |
| Fuse link covers | Thermoplastic, high resistance to temperature Flammability: (UL94) V2 Glow wire test: (IEC-60695) 850ºC |
| Accessory terminals | Tin plated brass Zinc plated steel screws |
| Rated current | 160A |
| Rated voltage | 690V 800V |
| Power dissipation | 12W (according to IEC60269-2) 25W (maximum) |
| Protection index | IP00 / IP20 |
| Ambient temperature of service | -20°C ... 80°C |
| Storage temperature | -40°C ... 80°C |
 DO NOT OPERATE UNDER LOAD |
 SAFETY NOTICE Please capture the following QR code and read our safety notice carefully before installing our products.  |
Standards
IEC/EN 60269-1
IEC/EN 60269-2
DIN 43620
Dimensions
Weight
| 1P | 3P | |
| STANDARD | 120gr | 370gr |
| WITH COVER SHIELDS | - | 430gr |
| WITH IP20 PROTECTION | - | 465gr |
Accessories
The fuseholder allows using simultaneously a microswitch for NH fuse links and IP20 protection accessories.
Compatible
 |
 |
 |
 |
 |
 |
|
| NH000 gG NH fuse link 500V | NH00 gG NH fuse link 500V | NH000 gG NH fuse link 690V | NH00 gG NH fuse link 690V | NH000 aM NH fuse link | NH00 aM NH fuse link | |
| U | 500V | 500V | 690V | 690V | 690V | 500V 690V |
| In | 2A...100A | 125A | 160A | 2A...40A | 50A...100A | 6A...40A | 50A...160A |
| Breaking capacity | 120kA | 120kA | 80kA | 80kA | 80kA | 80kA 120kA |
Other sizes
 |
 |
 |
 |
 |
|
 |
 |
 |
 |
 |
|
|---|---|---|---|---|---|
| U | 690V | 690V 800V |
690V 800V |
690V 800V |
690V |
| IN | 160A | 250A | 400A | 630A | 1250A 2500A |
