Range
| SIZE | Un (V DC) | In (A) | POLES | FIXING | CONNECTION | REFERENCE |
|---|---|---|---|---|---|---|
| NH1 XL | 1500V | 200A | 1P | SCREW | SCREW | 358250  |
Technical data
| Contacts | Silver plated copper | |
| Body | Thermoplastic, high resistance to temperature Flammability: (UL94) V0 Glow wire test: (IEC-60695) 960ºC |
|
| Partition walls | Phenolic resin laminated | |
| Separators | Thermoplastic, high resistance to temperature Flammability: (UL94) V0 |
|
| Terminal covers | Thermoplastic, high resistance to temperature Flammability: (UL94) V0 Glow wire test: (IEC-60695) 960ºC |
|
| Rated current | 200A | |
| Rated voltage | 1500V DC | |
| Maximum power dissipation | 45W | |
| Rated impulse withstand voltage | 12kV U imp | |
| Withstand rating | UL | 30kA |
| IEC | 100kA | |
| Protection index | IP00 / IP20 ON TERMINALS | |
| Ambient temperature of service | -20°C ... 70°C | |
| Storage temperature | -40°C ... 80°C | |
 DO NOT OPERATE UNDER LOAD |
 SAFETY NOTICE Please capture the following QR code and read our safety notice carefully before installing our products.  |
|
Standards
IEC/EN 60269-1
IEC/EN 60269-2
IEC/EN 60269-6
UL4248-1 Fuse holders
UL4248-19 Photovoltaic fuse holders
Certifications
Dimensions
| A | B | C | D | E | F | G | H |
| 260 | 235 | 28 | 77,5 | 103,5 | 305 | M10 | 66 |
Weight 377gr
Accessories
The fuseholder allows using simultaneously a microswitch for NH fuse links and IP20 protection accessories.
Compatible
 |
|
| NH1 XL gPV 1500V DC fuse link | |
| U | 1500V DC |
| In | 40A...200A |
| Breaking capacity | 30kA |
Other sizes
 |
 |
|
 |
 |
|
|---|---|---|
| U | 1500V DC | 1500V DC |
| IN | 315A | 500A |
| Certifications |  |
|
